M2x2 Magnet Fiber Optical Switch
TheM2x2 optical switchis connected to the optical path by connecting or blocking the optical signal. the switch has non-mechanical configurations and activated via an electrical control signal. the switch also has build-in circulator and isolator functions. Products are widely used in aerospace and military equipment.
Performance Specifications
|
Parameters |
Unit |
Specifications |
|
Wavelength Range |
nm |
1520 ~ 1580 |
|
Test Wavelength |
nm |
1550 |
|
Insertion Loss1, 2 |
dB |
≤ 1.2 |
|
TDL |
dB |
≤ 0.30 |
|
PDL |
dB |
≤ 0.20 |
|
Return Loss |
dB |
≥ 50 |
|
Crosstalk |
dB |
Bidirectional ≥ 20 |
|
Unidirectional ≥ 35 |
||
|
Repeatability |
dB |
≤ ±0.01 |
|
Switching Time |
us |
≤ 100 |
|
Pulse Duration |
us |
≥ 200 |
|
Durability |
Cycles |
≥10 Bllions |
|
Switch Type |
NA |
Latching |
|
Operating Current |
mA |
≤ 200 |
|
Maximum Optical Power |
mW |
≤ 500 |
|
Operating Temperature |
℃ |
-5 ~ +70 |
|
Storage Temperature |
℃ |
-40 ~ +85 |
|
Dimension |
mm |
(L)34.0×(W)7.5×(H)7.5 ±0.2 |
Note: 1 Test at room temperature and SOP.
2 Excluding connectors, 0.2dB for one pair connectors.
Mechanical Dimensions (Unit: mm)
Electrical Drive
|
Type |
Status |
Optical Route |
Electric Drive |
|
|
M2x2 |
Pin 1 |
Pin 2 |
||
|
Bidirectional |
Ⅰ |
P1 —— P3 P1 —— P4 |
GND |
V+ |
|
Ⅱ |
P1 —— P4 P2 —— P3 |
V+ |
GND |
|
|
Unidirectional |
Ⅰ |
P1 → P3 P3 → P2 P2 → P4 P4 → P1 |
GND |
V+ |
|
Ⅱ |
P1 → P4 P4 → P2 P2 → P3 P3 → P1 |
V+ |
GND |
|
Functional Diagram
Ordering Information
FSW-M2x2-□-□-□-□-□-□-□
|
—□ |
—□ |
—□ |
—□ |
—□ |
—□ |
—□ |
|
Switch Type |
Fiber Type |
Voltage |
Wavelength |
Tube Type |
FiberLength |
Connector |
|
B： Bidirectional U： Unidirectional |
SM： SM，9/125 X： Others |
2.5： 2.5V X： Others |
1550： 1550nm X： Others |
250： 250um 900： 900um X： Others |
05： 0.5m±5cm 10： 1.0m±5cm X： Others |
OO：None FC：FC/PC FA：FC/APC SC：SC/PC SA：SC/APC LC：LC/PC X：Others |
