M1x8 Magnet Fiber Optical Switch
TheM1x8 optical switchis connected to the optical path by connecting or blocking the optical signal. the switch has non-mechanical configurations and activated via an electrical control signal. the switch also has build-in circulator and isolator functions. Products are widely used in aerospace and military equipment.
Performance Specifications
|
Parameters |
Unit |
Specifications |
|
Wavelength Range |
nm |
1520 ~ 1580 |
|
Test Wavelength |
nm |
1550 |
|
Insertion Loss1, 2 |
dB |
≤ 2.0 |
|
TDL |
dB |
≤ 0.30 |
|
PDL |
dB |
≤ 0.20 |
|
Return Loss |
dB |
≥ 50 |
|
Crosstalk |
dB |
≥ 40 |
|
Repeatability |
dB |
≤ ±0.01 |
|
Switching Time |
us |
≤ 100 |
|
Pulse Duration |
us |
≥ 200 |
|
Durability |
Cycles |
≥10 Billions |
|
Switch Type |
NA |
Latching |
|
Operating Current |
mA |
≤ 200 |
|
Maximum Optical Power |
mW |
≤ 500 |
|
Operating Temperature |
℃ |
-5 ~ +70 |
|
Storage Temperature |
℃ |
-40 ~ +85 |
|
Dimension |
mm |
(L)40.0×(W)33.0×(H)7.5 ±0.2 |
Note: 1 Test at room temperature and SOP.
2 Excluding connectors, 0.2dB for one pair connectors.
Mechanical Dimensions (Unit:mm)
Electrical Drive
|
Type |
Status |
Optical Route |
Electric Drive |
|||||||||||||||
|
Pin Group A |
Pin Group B |
Pin Group C |
Pin Group D |
Pin Group E |
Pin Group F |
Pin Group G |
Pin Group H |
|||||||||||
|
Pin 1 |
Pin 2 |
Pin 3 |
Pin 4 |
Pin 5 |
Pin 6 |
Pin 7 |
Pin 8 |
Pin 9 |
Pin 10 |
Pin 11 |
Pin 12 |
Pin 13 |
Pin 14 |
Pin 15 |
Pin 16 |
|||
|
M1×8 |
Ⅰ |
Com-P1 |
V+ |
GND |
V+ |
GND |
V+ |
GND |
V+ |
GND |
GND |
V+ |
V+ |
GND |
GND |
V+ |
GND |
V+ |
|
Ⅱ |
Com-P2 |
GND |
V+ |
GND |
V+ |
V+ |
GND |
V+ |
GND |
GND |
V+ |
V+ |
GND |
GND |
V+ |
GND |
V+ |
|
|
Ⅲ |
Com-P3 |
V+ |
GND |
GND |
V+ |
GND |
V+ |
GND |
V+ |
V+ |
GND |
V+ |
GND |
GND |
V+ |
GND |
V+ |
|
|
Ⅳ |
Com-P4 |
GND |
V+ |
V+ |
GND |
GND |
V+ |
GND |
V+ |
V+ |
GND |
V+ |
GND |
GND |
V+ |
GND |
V+ |
|
|
Ⅴ |
Com-P5 |
V+ |
GND |
GND |
V+ |
GND |
V+ |
V+ |
GND |
GND |
V+ |
GND |
V+ |
V+ |
GND |
GND |
V+ |
|
|
Ⅵ |
Com-P6 |
GND |
V+ |
V+ |
GND |
GND |
V+ |
V+ |
GND |
GND |
V+ |
GND |
V+ |
V+ |
GND |
GND |
V+ |
|
|
Ⅶ |
Com-P7 |
V+ |
GND |
GND |
V+ |
GND |
V+ |
V+ |
GND |
GND |
V+ |
V+ |
GND |
GND |
V+ |
V+ |
GND |
|
|
Ⅷ |
Com-P8 |
GND |
V+ |
V+ |
GND |
GND |
V+ |
V+ |
GND |
GND |
V+ |
V+ |
GND |
GND |
V+ |
V+ |
GND |
|
Functional Diagram
Ordering Information
FSW-M1x8-□-□-□-□-□-□-□
|
—□ |
—□ |
—□ |
—□ |
—□ |
—□ |
—□ |
|
Switch Type |
Fiber Type |
Voltage |
Wavelength |
Tube Type |
FiberLength |
Connector |
|
B： Bidirectional |
SM： SM，9/125 X： Others |
2.5： 2.5V X： Others |
1550： 1550nm X： Others |
250： 250um 900： 900um X： Others |
05： 0.5m±5cm 10： 1.0m±5cm X： Others |
OO：None FC：FC/PC FA：FC/APC SC：SC/PC SA：SC/APC LC：LC/PC X：Others |
