Mechanical Optical Switches
2×4 Mechanical Optical Switch
2x4 Mechanical Optical Switch The 2X4 fiber optic switch connects optical channels by directing or blocking an incoming optical signal into the output fiber. This is achieved using a patent pen- ding op to-mechanical configuration and activated via an electric
Communication Products
Product Overview
2×4 Mechanical Optical Switch
The 2X4 fiber optic switch connects optical channels by directing or blocking an incoming optical signal into the output fiber. This is achieved using a patent pen- ding op to-mechanical configuration and activated via an electrical control signal. Latching version preserves the selected optical path after the drive signal has been removed, while the non-latching versions default to either the open or closed state when power is removed. The switch has integrated electrical position sensors. The new material based advanced design significantly reduces moving part position sensitivity, offering unprecedented high stability as well as unmatched low cost.
Specifications
|
Parameters |
Specifications |
Unit |
|
Operating Wavelength |
1260~1620(SM)、850(MM) |
nm |
|
Insertion Loss |
≤1.2 |
dB |
|
Wavelength Dependent Loss |
≤0.40 |
dB |
|
Polarization Dependent Loss |
≤0.05 |
dB |
|
Temperature Dependent Loss |
≤0.20 |
dB |
|
Return Loss |
SM≥50 MM≥30 |
dB |
|
Cross Talk |
SM≥55 MM≥35 |
dB |
|
Switch Time |
≤8 |
ms |
|
Repeatability |
≤±0.02 |
dB |
|
Durability |
≥107 |
times |
|
Operating Voltage |
3 or 5 |
V |
|
Switch Type |
Non-Latching/Latching |
/ |
|
Operating Temperature |
－20~＋70 |
℃ |
|
Storage Temperature |
－40~＋85 |
℃ |
|
Optical Power |
≤500 |
mw |
|
Dimension |
52.7L×37.2W×10.0H |
mm |
Pin Configurations
|
Type |
State |
Electric Drive |
Status Sensor |
||||||
|
2×4 |
Pin 1 |
Pin 5 |
Pin 6 |
Pin 10 |
Pin 2-3 |
Pin 3-4 |
Pin 7-8 |
Pin 8-9 |
|
|
Latching |
0 |
— |
— |
GND |
V＋ |
Close |
Open |
Open |
Close |
|
1 |
V＋ |
GND |
— |
— |
Open |
Close |
Close |
Open |
|
|
Non-Latching |
0 |
— |
— |
— |
— |
Close |
Open |
Open |
Close |
|
1 |
V＋ |
— |
— |
GND |
Open |
Close |
Close |
Open |
|
|
NO. |
Optical Route |
Relay |
|||||
|
1 |
2 |
3 |
4 |
5 |
6 |
||
|
1 |
A-1、B-2 |
0 |
0 |
0 |
1 |
0 |
1 |
|
2 |
A-1、B-3 |
1 |
1 |
0 |
1 |
1 |
1 |
|
3 |
A-1、B-4 |
1 |
1 |
0 |
1 |
1 |
0 |
|
4 |
A-2、B-1 |
0 |
1 |
0 |
1 |
0 |
1 |
|
5 |
A-2、B-3 |
1 |
1 |
1 |
1 |
1 |
1 |
|
6 |
A-2、B-4 |
1 |
1 |
1 |
0 |
1 |
1 |
|
7 |
A-3、B-1 |
0 |
0 |
1 |
1 |
1 |
1 |
|
8 |
A-3、B-2 |
0 |
1 |
1 |
1 |
1 |
1 |
|
9 |
A-3、B-4 |
1 |
1 |
1 |
0 |
0 |
1 |
|
10 |
A-4、B-1 |
0 |
0 |
1 |
1 |
1 |
0 |
|
11 |
A-4、B-2 |
0 |
1 |
1 |
1 |
1 |
0 |
|
12 |
A-4、B-3 |
1 |
1 |
1 |
0 |
0 |
0 |
Mechanical Dimensions (Unit:mm)
Optical Route
Ordering Information
|
RD-FSW |
-2×4- |
-Wavelength- |
-Switch Type- |
-Voltage- |
-Fiber Type- |
-Package- |
-Fiber length- |
-Connector- |
|
1060＝1 C＋L＝2 1310＝3 1410＝4 1550＝5 650＝6 780＝7 1260-1610=A 1310/1550＝9 850=8 Special＝0 |
Latching＝1 Non-latching＝2 Special＝0 |
3V=3 5V=5 Special＝0 |
SM28=1 50/125=5 62.5/125=6 Special＝0 |
Bare fiber=1 900um tube=3 Special＝0 |
0.25m=1 0.5m=2 1.0m=3 Special＝0 |
None=1 FC/PC=2 FC/APC=3 SC/PC=4 SC/APC=5 ST/PC=6 LC/PC=7 Duplex LC=8 Special＝0 |
